Thermaltake Smart RGB 700w Power Supply

  • Type: Intel ATX 12V 2.3
  • Max. Output Capacity: 700W
  • Color: Black
  • PFC (Power Factor Correction): Active PFC
  • Power Good Signal: 100-500 msec
  • Hold Up Time: 16msec (minimum) within 60% load
  • Input current: 12A max
  • Input Frequency Range: 50 Hz – 60 Hz
  • Input Voltage: 100Vac – 240Vac
  • Cooling System: 120mm Fan: 1800 R.P.M. ± 10%
  • Efficiency: 80-87% efficiency @ 20-100% load
  • P/N: PS-SPR-0700NHFAWx-1
  • Protection: OVP, OPP, SCP


  • Smart RGB 700 Watt is a power supply crafted for a guy who is looking to squeeze in a good PSU in his tight budget.
  • With 700w of power, this should provide more than enough for the vast majority of gaming PC’s and as such, for a low retail price non-modular power supply might seem a tempting choice.
  • Could this, therefore, be the perfect gaming power supply for those on a budget? – Lets put it to the test to find out!


  • This Thermaltake Smart RGB power supply comes with a single +12V rail which outputs 648w through a single rail.
  • As this is a non-modular power supply, all the cables come pre-attached to the power supply and can not be removed.
  • Despite this, you are provided with a good variety that should suit most systems. It is, of course, always advisable that you check to ensure that you are going to have enough to suit your build.
    • High amperage single +12V rail design.
    • 500w of continuous output at 40c.
    • 80 PLUS 230V EU Internal Certified
    • 10 LED light bulbs for brighter effects.
ModelSmart RGB 700W
SeriesSmart RGB Series
Part NumberPS-SPR-0700NHFAWx-1
TypePower Supply
Compliant withATX 12V 2.3
Efficiency80 PLUS® Standard  (80-87% efficiency @ 20-100% load)
Dimensions 150mm(W)x86mm(H)x140mm(D)
AC INPUTInput Voltage : 230V
Input Current : 12A max
Frequency : 50-60Hz
DC OUTPUT+3.3V+5V+12V-12V+5Vsb
PFC ?Power Factor Correction?Active PFC
Power Good Signal100-500 msec
Hold Up Time16msec (minimum) within 60% load
Input current12A max
Input Frequency Range50 Hz – 60 Hz
Input Voltage100Vac – 240Vac
Operating Temperature5? to +40?
Operating Humidity20% to 85%,non-condensing
Storage Temperature-40 ? to +55 ?
Storage Humidity10% to 95%, non-condensing
Cooling System120mm Fan: 1800 R.P.M. ± 10%
MTBF100,000 hrs minimum
Safety ApprovalCE/CB/TUV/ UL/ FCC/ EAC
ProtectionOVP, OPP, SCP
